9.6 m Heavy-Duty PU Foam Refrigerated Truck Body
9.6 m heavy-duty refrigerated truck body with one-piece PU foam insulation, about 57.8 m³ of capacity and a 3,000 kg/m² floor, supporting deep-freeze operation to -30 °C.
Product Description
High-capacity mainstay for trunk cold chain, with a heavy-duty load structure and deep-freeze capability down to -30 °C.
Product Introduction
The 9.6 m heavy-duty refrigerated truck body is built with the one-piece PU foam process, so the insulation layer is formed in a single shot with no seams or cold bridges. With an interior length of 9.66 m and a cargo volume of about 57.8 m³, it is a high-capacity choice for trunk cold-chain transport.
The body is reinforced for heavy-duty use: a strengthened high-strength steel subframe with an anti-corrosion coating supports a 3,000 kg/m² floor rating that handles pallet stacking and heavy cargo. Standard panel thickness is 100 mm, with an optional upgrade to 120 mm. The temperature range of -30 °C to +15 °C covers deep-freeze requirements. The body fits heavy-duty truck chassis in the 16–25 t gross vehicle weight range, making it suitable for long-distance trunk and cross-region cold-chain operations.
Factory & Process Credentials
Binglingfang (Qingdao Yakai Automotive Industry And Trade Co., Ltd.)'s refrigerated vehicle line covers light trucks, medium trucks, heavy trucks, and refrigerated semi-trailers across the full range, backed by two in-house production lines for polyurethane panels and GRP panels that ensure consistent panel quality and support custom manufacturing. The company holds a WMI (World Manufacturer Identifier) certificate and its products carry CCC certification. Its vehicles are exported to more than 50 countries and regions, and its major customers include JD Logistics, China Post, and well-known express carriers such as STO, ZTO, YTO, and Yunda.
Why Choose This Product?
- Industry-leading quality and reliability
- Energy-efficient design for cost savings
- Comprehensive warranty and support
- Easy maintenance and serviceability
